Technological Parameters:
|
Model |
QH-1800DS |
QH-2400DS |
QH-2700DS |
QH-3000DS |
|
Max Sheet Size(A+B)x2(mm) |
3600 |
4800 |
5400 |
6000 |
|
Min Sheet Size(A+B)x2(mm) |
1060 |
1060 |
1060 |
1060 |
|
Max Sheet Length(mm) |
1450 |
2250 |
2550 |
2850 |
|
Min Sheet Length(mm) |
350 |
350 |
350 |
350 |
|
Max Sheet Width(mm) |
800 |
1200 |
1350 |
1500 |
|
Min Sheet Width(mm) |
180 |
180 |
180 |
180 |
|
Min Sheet Height(C D C)(mm) |
400 |
400 |
400 |
400 |
|
Stitching Pitch(mm) |
20-120 |
20-120 |
20-120 |
20-120 |
|
No of Stitching |
1-99 |
1-99 |
1-99 |
1-99 |
|
Machine Speed (Stitch/min) |
500 |
500 |
500 |
500 |
|
Power Required(HP) |
13 |
18 |
18 |
18 |
|
Max Stopper Measurement |
450mm(E) |
600mm© |
600mm© |
600mm© |
|
Max TS Width |
40mm(E) |
40mm(E) |
40mm(E) |
40mm(E) |
|
Min First Stitch Pitch |
25mm(D) uncovered |
25mm(D) uncovered |
25mm(D) uncovered |
25mm(D) uncovered |
